Upper Computer Software(Video):
The GCM387 is a high-performance, cost-effective 3D electronic compass. It employs innovative 24-point rotating acquisition and calibration technology, effectively enhancing anti-interference capabilities while simplifying operation. An integrated high-precision accelerometer supports full-range (±180°) tilt compensation, ensuring accurate heading data even under complex attitude conditions. It maintains stable measurement accuracy in environments with fixed magnetic field interference and supports flexible configuration via RS232/TTL dual-mode communication interfaces.
This product integrates a triaxial magnetometer and a triaxial accelerometer, featuring excellent resolution and strong noise suppression capabilities. It achieves low power consumption and high stability in a compact design. Suitable for handheld devices, mobile terminals, antenna stabilization, vehicle navigation, and system integration, it meets the diverse application needs for high-performance orientation measurement.
Technical Characteristics
❖ Azimuth accuracy: 0.5°;
❖ Roll angle measurement range: ±180°;
❖ Tilt resolution: 0.1°;
❖ Tilt accuracy: <0.2° (full range);
❖ Standard RS232/TTL output interface optional;
❖ With hard magnet, soft magnet and tilt compensation.
Application Field
❖ Marine navigation and surveying ❖ GPS integrated navigation system
❖ Antenna servo control ❖ Infrared imager integration
❖ Laser ranging equipment collaboration ❖ Map completion system support
❖ ROV underwater robot navigation ❖ Marine survey instrument support
❖ Special robot applications
Performance Parameters
|
GCM387
|
Parameter Indicators
|
|
Compass heading parameters
|
Optimal heading accuracy
|
0.5°
|
|
Resolution
|
0.1°
|
|
Compass Tilt Parameters
|
Pitch accuracy
|
0.1°<15°(Measurement Range)
|
|
0.1°<30°(Measurement Range)
|
|
0.1°<60°(Measurement Range)
|
|
0.2°<85°(Measurement Range)
|
|
Pitch roll range
|
±85°
|
|
Roll accuracy
|
0.1°<15°(Measurement Range)
|
|
0.1°<30°(Measurement Range)
|
|
0.1°<60°(Measurement Range)
|
|
0.2°<180°(Measurement Range)
|
|
Roll tilt range
|
±180°
|
|
Resolution
|
0.1°
|
|
Compass Tilt Parameters
|
Hard iron calibration
|
Yes
|
|
Soft iron calibration
|
Yes
|
|
Magnetic field interference calibration method
|
24-point rotation acquisition calibration
|
|
Interface Characteristics
|
Startup delay
|
<50ms
|
|
Maximum output rate
|
20Hz/s
|
|
Communication rate
|
2400 to 115200 baud
|
|
Output format
|
Binary high-performance protocol
|
|
Power Supply
|
Supply voltage
|
Binary high-performance protocol
|
|
Current (typical)
|
50mA
|
|
Sleep mode
|
TBD
|
|
Electromagnetic Compatibility
|
Compliant with EN61000 and GBT17626
|
|
Mean Time Between Failures (MTBF)
|
≥99000hours / time
|
|
Insulation Resistance
|
≥100 megohms
|
|
Shock Resistance
|
100g@11ms, triaxial (half-sine wave)
|
|
Vibration Resistance
|
10grms,10～1000Hz
|
|
Product Dimensions
|
33×27×9.5mm
|
|
Weight
|
<15g
|
PIN Definition
|
PIN/Thread Color
|
Definition
|
Description
|
|
Black
|
GND
|
GND
|
|
Red
|
DC 5V
|
VCC
|
|
Yellow
|
TTL/RS232_RXD
|
Receive Data
|
|
Green
|
TTL/RS232_TXD
|
Transmit Data
|
Product Dimensions
PCBA Dimensions: L33×W27×H9.5mm
Installation Dimensions: L28.5×W22.6×H2mm
Recommended screws: 4M3 screws (copper screws)
